C5356X16 MJ x FJX 45° - Swivel Nut Elbow - Steel 6502-16-16-4
$19.02
In stock: 116 available
1
Product Details
Details
• Swivel Nut Elbow
• MJ x FJX 45°
• 1st) 1" Male 37° JIC Flare (1 5/16 - 12 Thread)
• 2nd) 1" Female JIC Swivel (1 5/16 - 12 Thread)
• Forged Carbon Steel
• RoHS Compliant CR6 Free (Clear Zinc Trivalent) Plating
• PCC World-Class Quality Process
• Made to SAE J514 # 070321
• Working Pressure 3,600 PSI (4:1 Burst)
• Burst Pressure 14,400 PSI
• MJ x FJX 45°
• 1st) 1" Male 37° JIC Flare (1 5/16 - 12 Thread)
• 2nd) 1" Female JIC Swivel (1 5/16 - 12 Thread)
• Forged Carbon Steel
• RoHS Compliant CR6 Free (Clear Zinc Trivalent) Plating
• PCC World-Class Quality Process
• Made to SAE J514 # 070321
• Working Pressure 3,600 PSI (4:1 Burst)
• Burst Pressure 14,400 PSI
Crossover Part Numbers
Eaton-Aeroquip Ref: 2070-16-16SEaton-Weatherhead Ref: C5356x16
Parker Ref: 16 V6X-SSAE Ref: 070321
Specs
Fluid Product: ConnectionProduct Type: FittingsMedia: HydraulicMaterial: SteelOrientation: 45° ElbowTube O.D.: 1"1 - Thread Type: Male JIC
1 - Size: -16 (1")1 - Thread: 1 5/16 - 122 - Thread Type: Female JIC Swivel2 - Size: -16 (1")2 - Thread: 1 5/16 - 12C - Nut Hex: 1 1/2M - Leg Length: 1.47
N - Leg Length: 1.75Y - Flats: 1 5/16Working PSI: 3,600Burst PSI: 14,400Working BAR: 248Burst BAR: 993
